Rockford Fosgate - P500-12P Single 12" 300 Watt Powered Subwoofer

Rockford Fosgate - P500-12P Single 12" 300 Watt Powered Subwoofer

Regular price $939.00
Regular price Sale price $939.00
Sold out
Tax included.

Punch 12" 500-Watt Powered Enclosure P500-12P



The Punch P500-12P is an "all in one" solution for adding serious bass to Hatchbacks, Sedans, and SUVs. This model features a 12"...

17 people are viewing this right now

AvailabilityOut of stock

SKU: P500-12P
Category: Unknown Type
View full product details

Punch 12" 500-Watt Powered Enclosure P500-12P



The Punch P500-12P is an "all in one" solution for adding serious bass to Hatchbacks, Sedans, and SUVs. This model features a 12" high output woofer with a 500-watt internal amplifier and a high output vented enclosure that's great for sedan and hatchback applications. The enclosure features quick release input and power connectors for easy removal when extra space is required.

OVERVIEW

The Punch 500-12P is a self-contained subwoofer enclosure with built-in amplifier. This "all in one" solution is great for systems that need extra Punch on the low-end of the frequency spectrum. The 12" high output subwoofer is impedance optimized for the built in 500-watt class-D amplifier that features a low-pass crossover, bass EQ and phase switch. You can change the amount of bass on the fly with the included remote level control. The slot port provides powerful output at lower frequencies for enhanced bass reproduction. The enclosure can be connected via speaker level inputs for connection to factory systems, or traditional line level inputs for aftermarket systems. It also features an intelligent auto turn-of/off circuit that eliminates the need for a separate turn-on wire. The enclosure itself is precision designed and constructed using MDF (Medium Density Fiberboard) for the best acoustical properties and covered with heat activated vinyl finish to resist marks. The enclosure also features a quick-release connectors for easy removal when you need extra cargo space.



FEATURES AT A GLANCE

  • 1 Year Warranty
  • Remote bass level control included
  • Thermal and over/under voltage protection
  • Intelligent auto turn on/off function
  • Robust Power/Ground connections
  • Adjustable 12db/Octave low pass crossover
  • Designed For Hatchback, Sedan, and SUV Applications
  • Optimized 12" Low Impedance Woofer
  • On Board Phase Switch
  • Quick Input Connections for Easy Removal
  • On Board Adjustable Bass EQ
  • Precision Constructed MDF Enclosure with Heat Activated Vinyl Finish
  • 500 Watt Class-D Amplifier with Optimized "Closed Loop" Design
  • Separate low level and speaker level inputs
Woofer Size
12"
Woofer Quantity
1
Woofer Series
Proprietary
CEA-2031 Compliant

Nominal Impedance
Enclosure Material
5/8" MDF (Medium Density Fiberboard)
Power Handling
(Watts RMS)
500 Watts RMS
Speaker Connector
Enclosure Type
Ported
Crossover Controls
Variable 50 Hz to 200 Hz
12dB/Octave Butterworth
Input Switch
High-Level (Speaker Line)
Low-Level (RCA)
Power Wire Gauge
B+/GND: 8 AWG
REM: 18 AWG
Power Input Connector
Quick Disconnect
Input Sensitivity
Low-Level: 150 mV to 6 V
High-Level: 300 mV to 12 V
Phase Control
0° to 180°
Tone Controls
Bass Boost
0 dB to +12 dB @ 45 Hz
Heatsink Type
Extruded Aluminum
Input Impedance
20k Ohms
Remote Control
Punch Level Control (Included)Auto Turn-On Selector
Remote Trigger
DC Offset Sense
Audio Sense
Signal Input
Low/High-Level: 1 RCA Pair (L/R Summed)
Frequency Response
30 Hz to 200 Hz
CEA-2006 Compliant

Integrated Amplifier
500 Watts RMS
Circuit Topology Class
Class-D
Visual Indicators
Power/Protect LED
Fuses
30 Amp (2 x 15 Amp ATO Fuse)
Cooling
Convection
Dimensions
Box H x W x D
Wedge H x W x D1 x D2
15.00” x 24.76” x 10.91 x 7.71”
(38.1 cm x 62.9 cm x 27.7 cm x 189.2 cm)
Shipping Weight
48.2 Lbs. (21.9 kg)
