BEST IN CLASS ALL IN ONE 5 CHANNEL AMPLIFIER

The TH1400.5 five-channel amplifier from MTX Audio powers your entire car audio system with full-range clarity and deep, rich bass. Designed with dedicated channels for both speakers and a subwoofer, this compact amp delivers powerful, 85%+ efficiency, performance and precise sound control for any setup. With its compact size, advanced protection features, and included bass control remote, it’s the perfect all-in-one solution for audiophiles.

COMPLETE AUDIO POWER IN ONE SYSTEM

The TH1400.5 THUNDER amplifier is the perfect blend of versatility and performance. With four full-range channels delivering up to 100W RMS each at 2Ω, plus a subwoofer channel capable of 800W RMS at an impressive 1Ω load, you will have more than enough power for whatever you want to listen to. Whether it’s crisp highs, rich mids, or booming bass, the TH1400.5 ensures every track hits perfectly.

CUSTOM SOUND, SIMPLIFIED

Take complete control of your sound with fully adjustable gain, crossover, and bass boost settings. Hidden under a sleek panel cover, these controls let you fine-tune every detail of your audio while maintaining a clean and stylish look. The included external bass control remote puts subwoofer adjustments right at your fingertips for quick, on-the-go tweaks.

EFFICIENT AND RELIABLE PERFORMANCE

Built with industry leading 85%+ efficiency, the TH1400.5 minimizes heat and power consumption without sacrificing output. Advanced protection circuits and an LED status indicator keep your system running smoothly, alerting you to any potential issues so you can enjoy uninterrupted music on every drive.

BIG POWER IN A COMPACT DESIGN

The TH1400.5 boasts impressive power and a compact footprint that fits easily into tight installation spaces. The stylish chassis complements any vehicle interior, combining form and function to elevate your audio system both visually and sonically. The Dyno Certificate included will ensure that your amplifier potential exceeds the rated amount and gives you the power you deserve.

DIMENSIONS

• A - Length: 14 ¹⁄₂” (367mm)
• B - Width: 7” (176mm)
• C - Depth: 2” (50mm)
• Weight: 9.06Lbs (4.11Kg)

FEATURES

• 1400 Watts RMS Power Output (Tested @ 2750W RMS)
• Reliable Subwoofer-Range Class-D Circuit Design
• Compact Size for Flexible Installation
• 10V High-Level Audio Input Compatibility
• High-Quality Tiffany-Style RCA
• Input Power and Protection LED Indicator Light
• Surface Mount Component Technology
• Direct Insert Power and Speaker Terminals
• Thermal, Short, and Over/Under Voltage Protection
• Clip Detection Light for Tuning Optimization
• Dyno Power Rating Certificate (Example photo attached)

RATINGS

• CEA2006-D compliant - A true RMS power rating
• RECOMMENDED FUSE RATING: 200A - 250A
• MINIMUM POWER WIRE RATING: 0 AWG (8.3MM)

SPECIFICATIONS

• 5-CHANNEL
• Topology: CLASS D
• 4Ω RMS Power Output: 100W X 4 CHANNELS + 300W (Tested @ 231W RMS X 4 + 564W RMS)
• 2Ω RMS Power Output: 150W X 4 CHANNELS + 500W (Tested @ 352W RMS X 4 + 911W RMS)
• 4Ω RMS Bridged Power Output: 300W X 2 CHANNELS (Tested @ 704W RMS X 2)
• 1Ω RMS Subwoofer Power Output: 800W (Tested @ 1342W RMS)
• THD: < 0.4%
• Signal to Noise Ratio: > 95DB
• Frequency Response: 20HZ - 20KHZ (CH1-4)
• 20HZ - 250HZ (SUB)
• Crossover: 40HZ - 400HZ (CH1-4) 50HZ - 250HZ (SUB)
• Subsonic Filter: 10HZ - 55HZ (SUB)
• Maximum Input Signal: 10V
• Warranty Period: 12 MONTHS FROM DATE OF INITIAL PURCHASE
