Specifications
Thiele/Small Parameters
44CWCS84 T/S Parameters
Size (IN.,CM)
8, 20
Impedance (OHMS)
4 SVC
Recommended Amplifier Power (watts RMS)
200
Peak Power (watts, per ANSI/CTA-2031-A)
400
Sensitivity (dB 1w/1m)
85.6
Mounting Depth (in, cm)
3-7/8, 9.8
Mounting Diameter (in, cm)
7, 17.7
Min Sealed Box Vol (cu. ft, L)
0.5, 14.2
Max Sealed Box Vol (cu. ft, L)
1.2, 34
Min Vented Box Vol (cu. ft, L)
0.66, 18.7
Max Vented Box Vol (cu. ft, L)
1.2, 34
