CS Series CSS694
The CS 6x9-Inch Component Speakers are built for awesome sound that plays as long as the ride takes you.
CS components include Titanium tweeters and two-way...
Availability: Low stock: 1 left
Couldn't load pickup availability
CS Series CSS694
The CS 6x9-Inch Component Speakers are built for awesome sound that plays as long as the ride takes you.
CS components include Titanium tweeters and two-way crossovers with tweeter level control let you customize your sound for the best sonic quality.
These KS speakers work best with 150 watts of recommended power. See below for more details.
| Woofer Size | in [mm] |
| 6x9 [160x230] |
| Tweeter Size | in [mm] |
| 3/4 [20] |
| Dome Material |
| Titanium |
| Peak Power | [watts] |
| 450 |
| Continuous Power | [watts RMS] |
| 150 |
| Effective Frequency Range | Hz |
| 30-21k |
| Woofer Mounting Hole Diameter | in [mm] |
| 5 5/8 x 8 7/16 [143x215] |
| Woofer Bottom Mount Depth | in [mm] |
| 3 3/16 [81] |
| Flush Mounting Tweeter Hole Diameter | in [mm] |
| 1 9/16 [40] |
| Flush Mount Tweeter Depth | in [mm] |
| 9/16 [14.5] |
| High Pass | dB, at Frequency | Hz |
| 12, 4000 |
| Low Pass | dB, at Frequency | Hz |
| 12, 4000 |
| High Frequency Output Attenuation | dB |
| 0, 3, & 6 |
| Bolt-Thru Grilles |
| Yes |
