55 Segment 1.5 Line Text Display
Built-in DAB Tuner & BT
Direct Bluetooth Control Key
Multi-Color Illumination
13 Band EQ & DTA
Short Chassis
2 Preouts 2.5V
Smartphone Connectivity
By...
Availability: In stock
Couldn't load pickup availability
55 Segment 1.5 Line Text Display
Built-in DAB Tuner & BT
Direct Bluetooth Control Key
Multi-Color Illumination
13 Band EQ & DTA
Short Chassis
2 Preouts 2.5V
Smartphone Connectivity
By connecting your smartphone and receiver wirelessly,
your driving time will be more fun and convenient.
Music Mix - High Quality Music streaming x 5 devices
Up to 5 Bluetooth® devices can be paired to the head unit at the same time. You can enjoy audio streaming just by switching the devices among your friends.
Dual Phone Connection
While you are connected through Bluetooth, with a touch of a button you can switch between two phones.
KENWOOD Remote App Compatible
Download the free app “KENWOOD Remote“.You can change audio sources or adjust audio settings like “Time Alignment” or “13-Band EQ” from your smartphone.
The Best Audio Experience
Sound quality enthusiasts will love the playback support of various types of music formats, including compatibility with FLAC files. Simple sound customization is also available with its built-in 13-Band EQ and Digital Time Alignment.
Additional Features
|
FM |
Frequency Range(MHz) | 87.5MHz to 108.0MHz |
|---|---|---|
| (Frequency step) | (50kHz) | |
| Usable Sensitivity | 6.2 dBf | |
| S/N30dB | (0.56μV/75Ω) | |
| Quieting Sensitivity | 15.2 dBf | |
| DIN S/N 46dB | (1.58μV / 75Ω ) | |
| Frequency Response | 30Hz to 15kHz | |
| (±3.0dB) | ||
| S/N(dB) | 68.0dB(MONO) | |
| Stereo Separation | 40dB(1kHz) | |
| MW (AM) | Frequency Range(kHz) | 531kHz to 1611kHz |
| (Frequency step) | (9kHz) | |
| Usable Sensitivity | 28.5μV | |
| (S/N 20dB) | ||
| LW | Frequency Range(kHz) | 153kHz to 279kHz |
| (Frequency step) | (9kHz) | |
| Usable Sensitivity | 45μV | |
| (S/N 20dB) | ||
| DAB | Frequency Range | BAND III= 174.928MHz to 239.200MHz |
| Sensitivity | -100dBm | |
| S/N | 90dB | |
| DAB Antenna Connector | Connector type | SMB |
| Output Voltage | DC 12V | |
| Maximum Current | <100mA | |
| USB I/F | USB | USB 1.1 / 2.0 Full speed |
| File System | FAT12 / 16 / 32 | |
| Maximum Supply current | DC5V(DC logo) 1.5A | |
| Frequency Response | 20Hz to 20kHz(±1dB) | |
| S/N Ratio (dB) | 99dB(1kHz) | |
| Dynamic Range | 93dB | |
| Channel Separation | 89dB | |
| MP3 Decode | Compliant with MPEG-1/2 Audio Layer-3 | |
| WMA Decode | Compliant with Windows Media Audio | |
| AAC Decode | AAC-LC ".aac", ".m4a" files | |
| WAV Decode | Linear-PCM | |
| FLAC Decode | FLAC file (Up to 96kHz/24bit) | |
| Preout Level(mV)/Load -Unbalanced | 2500mV/10kΩ (USB) | |
| Preout Impedance(Ω) | ≦600Ω | |
| Speaker Impedance(Ω) | 4 to 8Ω | |
| AUX Input | Frequency Response | 20Hz to 20kHz ±3dB |
| （4Ω,1kHz,10%THD） | 1000mV | |
| Input Impedance | 30kΩ | |
| AMP | PWR(MAX) | 50Wx4 |
| Full Bandwidth Power (at less than 1%THD) | 22Wx4 | |
| TONE | Band1 | 62.5Hz ±9dB |
| Band2 | 100Hz ±9dB | |
| Band3 | 160Hz ±9dB | |
| Band4 | 250Hz ±9dB | |
| Band5 | 400Hz ±9dB | |
| Band6 | 630Hz ±9dB | |
| Band7 | 1kHz ±9dB | |
| Band8 | 1.6kHz ±9dB | |
| Band9 | 2.5kHz ±9dB | |
| Band10 | 4kHz ±9dB | |
| Band11 | 6.3kHz ±9dB | |
| Band12 | 10kHz ±9dB | |
| Band13 | 16kHz ±9dB | |
| Bluetooth | Version | Bluetooth 3.0 |
| Frequency Range | 2.402 to 2.480GHz | |
| RF Output Power (E.I.R.P.) | +4dBm (MAX), Power Class 2 | |
| Maximum Communication range | Line of sight approx.10m(32.8ft) | |
| Profile | HFP 1.6 (Hands Free Profile) | |
| SPP(Serial Port Profile) | ||
| PBAP(Phonebook Access Profile) | ||
| A2DP(Advanced Audio Distribution Profile) | ||
| AVRCP 1.5 (Audio/Video Remote Control Profile) | ||
| GENE | Operating voltage | 12V DC car battery |
| Installation Size (W) | 182(mm) | |
| (H) | 53(mm) | |
| (D) | 100(mm) | |
| Net Weight (Trim plate and Mounting sleeve: Included) | 0.7(kg) | |
