HD (1280 x 720)
Lens: F:2.0
Frame Rate: 30fps
Viewing Angle: Horizontal 180°/ Vertical 103°
Operating Voltage: 12V/24V
Operating Temperature: -30℃ to 85℃
IPX : IP67
Output: HD-TVI
Dimensions (WxHxD): 31.1mm x23.0mm x25.2mm
Weight: 33.2g (without cable)
Cable Length:
Camera Unit side 3.0m
DC Box Unit side 6.0m
Other 0.5m

High Definition View

Displaying the image in true 1280 x 720 (720P) High Definition on compatible receivers.

HDR (High Dynamic Range)

— Reducing “Blown out Highlights” and “Crushed Blacks” —
HDR helps to reduce “blown out highlights” and “crushed blacks” and ensure clear images in challenging environments, including backlit scenes in daylight, streetlight scenes at night and places where light-dark contrast is particularly severe.
