This install kit allows you to install a double DIN aftermarket headunit into your vehicle.
Specs:
Application: Double DIN
Colour: Gloss Black
Internal Dimensions: 200 mm W x 100 mm H (wings reduce width to 172mm)
External Dimensions:
Inclusions: Facia Kit, Metal Brackets, Speaker and power harness, Detailed Instructions.
Notes:
"FP9805S" includes a silver panel (fluorescent under black light).
"FP9805" includes a black panel.
This model is compatible with the Factory DVD car navigation system although the TV function is disabled.However, the TV function on the aftermarket car navigation system can operate.
The information-center-display including the clock and audio become disabled.
Automatic Level Control (ALC) becomes disabled.
For models without the Factory navigation system, there is no speed pulse signal from the vehicle side. For installation of a car navigation system, it is necessary to connect the speed pulse signal cord included in this set.
This set is compatible with model (Oct.2004-Nov.2005) with manual air conditioning controls. However, the information-center-display function becomes disabled.
Car models with the BOSE sound system use a separate amplifier. Optional sound system translator for MAZDA Models FP9811 is required for proper operation.
As cars with remote audio control switches on the steering wheel are disabled, installation of optional parts APUNISW5 enables the operation of an audio remote control switch on the steering wheel.
Beep sound for air conditioning control is disabled.
