Description

The Aerpro AMDVW13 9" Multimedia Receiver with Wireless Apple CarPlay, Android Auto and DAB+ suits Volkswagen EOS (2007-2014), Golf (2009-2013), Passat (2006-2015), Polo (2010-2014), Scirocco (2009-2014), Tiguan (2008-2014) vehicles with Blaupunkt factory amplifier.

Featuring a large 9" capacitive touchscreen display with a crisp 1024x600 resolution, this Multimedia Receiver has Apple CarPlay and Android Auto which can be used wireless or wired, built-in Bluetooth V5 for hands-free phone calls & wireless audio streaming, dual rear USB inputs, built-in DAB+ digital radio for crystal-clear sound and a wider range of stations, as well as an AM/FM radio tuner. Sound quality is superb with 50Wx4 max output, 13-band graphic EQ and time alignment capabilities, amplifiers can be added to the system via the 4V/5CH RCA preouts.

Supplied as a complete Head Unit Upgrade Kit, the Aerpro AMDVW13 includes all the parts required to complete the installation whilst maintaining important vehicle features such as Steering Wheel Control functionality, Vehice Climate Control, Parking Visualisation on the aftermarket display (if equipped) and the factory amplified system (model dependant**). A Surface Mount Camera is also included, delivering clear picture quality with a 110 degree field of view, optional parking guidelines and IP67 rating.

Important Information:

• Head Unit Upgrade Kits can vary between vehicle models, please use the Aerpro What Fits Your Car Guide to find the correct parts.
• Only suitable for vehicles with white MFD
• (**) Factory amplifier retention:
  • Compatible with factory Blaupunkt amplified systems.
  • Not compatible with factory Panasonic amplified systems, for these vehicles please use the Aerpro AMDVW2 or AMDVW12 Head Unit Upgrade Kit.
  • May need a trigger wired in for the amplifier.
• This head unit is sold as a kit which includes:
  • AM905D Multimedia Receiver
  • Matte Black Facia Kit
  • Infolink Steering Wheel Control Interface Harness
  • SWC Patch Lead
  • Amplifier Retention Harness
  • Antenna Adaptor
  • Universal Rear Camera

Features

• Complete Head Unit Upgrade Kit: Includes all the parts required to complete the installation and retain important vehicle features for Volkswagen Various Models 2006-2015 .
• Vehicle Feature Retention: Retains steering wheel controls including phone button and vehicle menu.
• Large 9" Capacitive Touchscreen Display: Crisp 1024x600 resolution with smooth, responsive control for easy navigation of maps, media, and menus.
• Wireless Apple CarPlay & Android Auto: Instantly access maps, music, calls, and messages without plugging in your phone, or connect via USB for wired operation and charging.
• Built-In DAB+ Digital Radio: Enjoy crystal-clear digital sound quality and a wider range of stations, plus AM/FM tuning with RDS for all your broadcast preferences.
• Bluetooth Hands-Free Calling & Audio Streaming: Bluetooth V5 with HD Voice support, internal and external microphone options, and full phonebook and audio streaming capability.
• USB Media Playback Support: Play music, videos, and photos directly from a USB drive in popular file formats.
• Surface Mount Camera Included: Clear picture quality with a 110 degree field of view, optional parking guidelines and IP67 rating — mountable as a front, rear or reverse camera.
• High-Power Audio with Advanced Tuning: 4 x 50W Max output, 5-channel 4V RCA preouts, 13-band EQ, time alignment, and subwoofer control for clear, powerful sound.
• Multi-Colour Key Illumination: Customisable 6-colour button lighting to match your vehicle's interior.

Specifications

AMDVW13 HEAD UNIT UPGRADE KIT SPECIFICATIONS:

• Kit Inclusions:
  • [AM905D] https://aerpro.com/am905d Multimedia Receiver
  • Matte Black Facia Kit
  • Infolink Steering Wheel Control Interface Harness
  • SWC Patch Lead
  • Amplifier Retention Harness
  • Antenna Adaptor
  • Universal Rear Camera
• Vehicle Feature Retention:
  • Steering Wheel Controls: Yes including phone button
  • Factory Reverse Camera: No
  • AUX Input: N/A
  • USB Input: N/A
  • Parking Tones: No
  • Factory Amplifier: Yes model dependant**
  • Vehicle Menu: Yes
  • Other: N/A

MULTIMEDIA RECEIVER SPECIFICATIONS:

• LCD Display:
  • Size: 9"
  • Resolution: 1024x600
  • Touch Screen: Capacitive
• OS System: Linux
• DIN Size: Fixed Screen Style Trapezoid
• Power Output:
  • MAX Power 4 Ohm : 4CH x 50W
• Media Playback: MP3 / MP4 / MKV / FLAC / Xvid
• Device Ports:
  • USB1 Rear : Apple CarPlay & Android Auto with Charging Function – 5V / 1.5A
  • USB2 Rear : Media with Charging Function – 5V / 1.5A
  • USB MAX Capability: FAT32_32GB
• Aux Inputs / Outputs:
  • Rear A/V Input RCA Type – 3pcs : Yes
  • Composite Video Output: Yes Two
  • Reverse Camera Input: Yes 720P AHD Compatible
  • Second Camera Input: Yes 720P AHD Compatible
• Smartphone Connectivity: CarPlay & Android Auto Wireless and Wired
• Bluetooth:
  • Bluetooth Built-In: Yes A2DP, AVRCP, HFP, PBAP
  • Bluetooth Version: V5
  • Microphone: Internal + External Microphone
  • ID3 Tag/Information Artist, Album, Song : Yes
  • HFP Profile: HFP 1.6 HD Voice
• Tuner:
  • DAB: Yes
  • AM/FM # of Presets : AM 12 / FM 18
  • FM Frequency Span MHz : 87.5–108.0MHz 0.05MHz Step
  • AM Frequency Span KHz : 522–1710KHz 9KHz Step
  • RDS: Yes
• RCA Preamp Outputs:
  • RCA Preamp Output: 4V, 5 Channel – 3 Pair Front / Rear / Subwoofer
  • Subwoofer Level Control: Yes
  • Preamp Voltage: 4V p-p
• Tone Control:
  • 13-Band EQ: 32/63/125/250/500/1K/2K/4K/8K/10K/12K/14K/16K
  • Loudness: Yes
  • LPF – Frequencies Sub : Yes
  • Preset EQs: 6+2 Custom
  • Time Alignment: Yes
• Other Features:
  • Steering Wheel Control: Yes, with Aerpro SWC Adaptor
  • OSD Language: English
  • LED Colour Buttons / Keys : 6-Colour Options Red, Yellow, Green, Blue, Purple, White
• Inclusions:
  • 9" Fixed Headunit Trapezoid
  • Mounting Hardware Screws
  • Wiring Harness with ISO Connection
  • AV, USB and Camera Harnesses
  • DAB Antenna
  • 3 Wire Learning SWC Lead
  • External Microphone with Mount
  • GPS Antenna with Adhesive Pad
  • QR Digital Manual Leaflet

Camera Specifications:

• Inclusions:
  • Surface Mount Camera wired
  • 6m of Video Cable RCA with in-line Reverse Trigger
• Mount Type: Surface Mount
• Camera Type: Front, Rear Or Reverse
• Lens Angle: 110 Degree

IMPORTANT INFORMATION:

• Head Unit Upgrade Kits can vary between vehicle models, please use the Aerpro What Fits Your Car Guide to find the correct parts.
• Only suitable for vehicles with white MFD
• ** Factory amplifier retention:
  • Compatible with factory Blaupunkt amplified systems.
  • Not compatible with factory Panasonic amplified systems, for these vehicles please use the Aerpro AMDVW2 or AMDV12 Head Unit Upgrade Kit.
  • May need a trigger wired in for the amplifier.
  • Please be aware when installing a High Definition Camera, the camera resolution will be reduced using this product.
